Blowers & Centrifugal Fans
Conventional Single Inlet Blower
Conventional single inlet blowers for general industrial ventilation, exhaust, and air supply applications.
Catalogue Specifications
Models and Technical Data
Catalogue values are shown in their published units. Final selection and operating-point suitability should be confirmed with SEM engineering.
| Type | I/P Supply | Amps (A) | Watts (W) | RPM | Airflow CMH | Airflow CFM | Static PR (mm-wc) | dBA | CAP µf | Amb. Temp °C | Weight Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SSB 53 S2 | 230V, 1Ø, 50Hz | 0.45 | 90 | 2750 | 450 | 265 | 42 | 65 | 4 | 60 | 3.4 |
| SSB 55 S2 | 230V, 1Ø, 50Hz | 0.5 | 120 | 2750 | 600 | 353 | 42 | 66 | 4 | 60 | 3.8 |
| SSB 60 S2 | 230V, 1Ø, 50Hz | 0.65 | 160 | 2750 | 650 | 382 | 45 | 68 | 4 | 60 | 4 |
| SSB 63 S2 | 230V, 1Ø, 50Hz | 0.7 | 170 | 2750 | 700 | 412 | 45 | 70 | 5 | 60 | 4.5 |
Tolerance ±5% on Specified values
Need help selecting a model?
Share your airflow, static pressure, supply and application requirements.
